Place of Origin:
Xi'an,China
Brand Name:
FHH
High Corrosion Resistance Titanium Angle 6000mm Length 12mm for Construction Projects
Titanium and titanium alloy angle have many excellent characteristics. These characteristics are mainly displayed in the following aspects:
Titanium alloy has a high strength, with a tensile strength of 686-1176mpa, thus giving it a high specific strength when compared to steel due to its lighter density of only 60%.
The hardness of titanium alloy (annealed) is measured at 32-38 HRC.
Titanium alloy (annealed) has an elastic modulus of 1.078×10-1.176×10MPa. This figure is half of that of steel and stainless steel.
Titanium alloy maintains its mechanical properties even in high temperatures. Its heat resistance is far greater than aluminum alloy, with a current operating temperature of 550-600℃. On the other hand, the strength of titanium alloy is increased compared to room temperature in low temperatures, with good toughness, and being able to maintain good performance even at -253℃.
Titanium alloy also features superb corrosion resistance. When subjected to the atmosphere, seawater, nitric and sulfuric acid, or other oxidizing media and strong alkalis, titanium’s resistance is superior to most stainless steel. This is mainly attributed to a thin, dense layer of titanium oxide film which forms on the surface when temperatures dip below 550°C.
| No. | Products | Dimension(mm) | Length(mm) | About Kgs per piece | remark |
| 1 | 3# angle | 30X30X3 | L=6000 | 4.73 | Equal sides |
| 2 | 3# angle | 30X30X4 | L=6000 | 6.15 | Equal sides |
| 3 | 4# angle | 40X40X3 | L=6000 | 6.38 | Equal sides |
| 4 | 4# angle | 40X40X4 | L=6000 | 8.34 | Equal sides |
| 5 | 5# angle | 50X50X3 | L=6000 | 8.03 | Equal sides |
| 6 | 5# angle | 50X50X4 | L=6000 | 10.54 | Equal sides |
| 7 | 6.3# angle | 63X63X4 | L=6000 | 13.46 | Equal sides |
| 8 | 6.3# angle | 63X63X5 | L=6000 | 16.62 | Equal sides |
| 9 | 8# angle | 80X80X5 | L=6000 | 21.41 | Equal sides |
| 10 | 8# angle | 80X80X6 | L=6000 | 25.42 | Equal sides |
| materials | Gr1,Gr2,Gr3,Gr4,gr5......etc | ||||
| Standards: |
GB/T706-2016,GB/T37520-2019,GB/T41750-2022,N/HL 001-2021,N/HL 002-2021,ASTM F67,AMS4928,ASTM F136,ASTM B348,BT1-0,TP270,TP550,TP450 etc.
|
||||
Titanium or titanium alloy angle have many excellent characteristics, titanium alloy processing materials are mainly reflected in the following aspects:
1. High strength. Titanium alloy has a high strength, its tensile strength is 686-1176mpa, and the density is only about 60% of steel, so the specific strength is very high.
2. High hardness. The hardness HRC of titanium alloy (annealed) is 32-38.
3. Low elastic modulus. The elastic modulus of titanium alloy (annealed) is 1.078×10-1.176×10MPa, which is about half that of steel and stainless steel.
4. Excellent high and low temperature performance. At high temperature, titanium alloy can still maintain good mechanical properties, its heat resistance is much higher than aluminum alloy, and the operating temperature range is wide, the current new heat-resistant titanium alloy operating temperature can reach 550-600 ℃; At low temperature, the strength of titanium alloy is increased compared with that at room temperature, and it has good toughness, and low temperature titanium alloy can maintain good toughness at -253℃.
5. Titanium angle has strong corrosion resistance. Titanium in the air below 550 ° C, the surface will quickly form a thin and dense titanium oxide film, so in the atmosphere, seawater, nitric and sulfuric acid and other oxidizing media and strong alkali, its corrosion resistance is better than most stainless steel.
| Name | Titanium Angle |
|---|---|
| Corrosion Resistance | High |
| Technique | Cold Bend |
| Standards | ASTM F67, AMS4928, ASTM F136, ASTM B348,BT1-0, TP270, TP550, TP450 Etc. |
| Color | Silver |
| Thickness | 3mm---10mm |
| Material | Gr1,Gr2,Gr3,Gr4,Gr5 |
| Length | 6000mm----12mmm |
| Shape | L Shape |
We provide a comprehensive technical support and service for Titanium Angle.
Q1: What is Titanium Angle?
A1: Titanium Angle is a product of FHH from Xi'an, China. It is a type of material used in many applications with excellent strength and corrosion resistance.
Q2: How much does it cost?
A2: The price of Titanium Angle depends on the quantity and size of the order. The minimum order quantity is 200kgs and the Supply Ability is 1000mg per month.
Q3: What is the packaging of Titanium Angle?
A3: All goods are packed by seaworth shipment materials.
Q4: How long is the delivery time?
A4: The delivery time is 5-8 days.
Q5: What payment terms are available?
A5: Payment terms are L/C, D/P, T/T.
